| Model | Numerical value | |
| Rated Lifting Capacity | kg | 3000 |
| Load Center Distance | mm | 500 |
| Power Mode | - | Diesel |
| Driving Mode | Sit-down | |
| Max. Lifting Height | mm | 3000 |
| Side Shift | / | |
| mast | Three-stage mast | |
| Free Lifting Height | mm | 100 |
| Guardrail height | mm | 2165 |
| Minimal Ground Clearance | mm | 135 |
| Seat to Top Guard Height | mm | 1050 |
| Overall Length (Without Fork) | mm | 2700 |
| Wheelbase | mm | 1700 |
| Front Overhang | mm | 478 |
| Rear Overhang | mm | 520 |
| Overall Width | mm | 1225 |
| Track (Front/Rear) | 1000/970 | |
| Fork Adjustment Range | mm | 1060-250 |
| Turning Radius (Inside/Outside) | mm | 80/2400 |
| Mast Tilt Angle (Forward/Backward) | ° | 6°/12° |
| Total Weight | kg | 4350 |
| Tire Type | Solid Tire | |
| Front Tire Size | 28X9-15-12PR | |
| Rear Tire Size | 6.5-10-10PR | |
| Service Brake | Hydraulic-Pedal Type | |
| Parking Brake | Mechanical-Manual Type | |
| Max Driving Speed | km/h | 20 |
| Max Gradient Angle | % | 20 |
| Max. Traction Force | kW | 20 |
| Battery | - | 12V80Ah |
| Engine Model | - | Xinchai C490BPG |
| Rated Power | KW/r.p,m | 40/2650 |
| Rated Torque | KW/r.p,m | 165/1800 |
| Bore * Stroke | 90*105 | |
| Number of Cylinders | 4 | |
| Displacement | L | 2.7 |
| Fuel Tank Capacity | L | 70 |
| Gear (Forward/Reverse) | 2/2 Manual Gearbox | |
